After replacing the front air bags I was having the same types of problems . If you have a gap tool re flash the suspension computer. I finally did that and have been good for months now. The computer learns as it goes and changes what it thinks is normal.
Drifting
Joined: Feb 2012
Posts: 49
Likes: 2
Update, I did find the leak, replaced both front air shocks. Would lower, rise, remain in normal height and the yellow/amber suspension fault would come on but truck rode fine.
That lasted 1 month.
Now, suspension kicks in, rear rises, both front shocks don't.
What I've done:
Rebuilt compressor with kit (worked for about 6 months before front leak issue).
Rebuilt Air Block Valve (to pinpoint leak)
Replaced Height Sensors with original parts (before spending big bucks on bags)
Replaced both front air shocks after recorded air leak.(didn't recalibrate after replacing)
All suspension fuses are fine.
So now, suspension fault, tire pressure fault, rear rises, front doesn't (either side).
I have this click that I hear when I shut the car off:
That lasted 1 month.
Now, suspension kicks in, rear rises, both front shocks don't.
What I've done:
Rebuilt compressor with kit (worked for about 6 months before front leak issue).
Rebuilt Air Block Valve (to pinpoint leak)
Replaced Height Sensors with original parts (before spending big bucks on bags)
Replaced both front air shocks after recorded air leak.(didn't recalibrate after replacing)
All suspension fuses are fine.
So now, suspension fault, tire pressure fault, rear rises, front doesn't (either side).
I have this click that I hear when I shut the car off:
Camel Trophy
Joined: Apr 2009
Posts: 4,244
Likes: 482
From: North of Seattle
EAS is a great invention but it definitely has its quirks. Last night (after driving in snow a bit) I went to lower my LR3 from Off-Road height into Access. It was still in 4-Lo and may have been in GGS Mode still. Anyway as soon as I did, it gave me a weird fault (engine was off). So I fired it up and read the code with my IIDTool. It was an issue with the "exhaust valve." It also wouldn't allow a Special Program to be selected from TR. I cleared everything and STILL it would not allow GGS to be selected, despite the EAS going up and down just fine. I cycled power and all was well.
I think this may have been blockage from some ice maybe???...or a cold-weather thing. Later, just for fun I went out and cycled the LR3 through all the EAS heights and even put it in GGS and 4-Lo and tried to lower it in Access (I believe it will kick you back to Normal regardless, perhaps after giving you the warning about bottoming out).
Anyway....glitch. My EAS has been doing this more lately; particularly after getting the AMK installed. A "communication error" here, a "not venting quickly enough" there....this one with the "exhaust valve." All are pretty inconsequential, especially with the IIDTool, but it makes me wonder, about the maturity of the retrofit kit for the AMK in the LR3.
Sorry Coil-over believers...I still love the EAS.
I think this may have been blockage from some ice maybe???...or a cold-weather thing. Later, just for fun I went out and cycled the LR3 through all the EAS heights and even put it in GGS and 4-Lo and tried to lower it in Access (I believe it will kick you back to Normal regardless, perhaps after giving you the warning about bottoming out).
Anyway....glitch. My EAS has been doing this more lately; particularly after getting the AMK installed. A "communication error" here, a "not venting quickly enough" there....this one with the "exhaust valve." All are pretty inconsequential, especially with the IIDTool, but it makes me wonder, about the maturity of the retrofit kit for the AMK in the LR3.
Sorry Coil-over believers...I still love the EAS.
Winching
Joined: Jul 2012
Posts: 547
Likes: 4
From: Jackson NJ
Could it be that it faulted because the engine was off?
I almost went to coils because of my frustrations but glad I didn't, with the iid tool I have the best of both worlds, insta-lift and comfortable ride.
I almost went to coils because of my frustrations but glad I didn't, with the iid tool I have the best of both worlds, insta-lift and comfortable ride.
Camel Trophy
Joined: Apr 2009
Posts: 4,244
Likes: 482
From: North of Seattle
Nahhh....I've dropped the suspension into Access with the engine off many times. It could be that some ice had built up around the area of an exhaust valve or tube. I'm not sure where all those areas are. I know the valve is on the compressor and that would be nearly impossible because of my sliders (but there ARE venting slots on the sliders in that area and I do NOT have the acoustic box bottom mounted) so there is a chance.
Anyway, it's quirky. These things make me mad because I still want it to be perfect. I guess I have to realize that at 11.5 years old, it's like the Millennium Falcon. Always in need of something, but still bad *** in a fight.
Anyway, it's quirky. These things make me mad because I still want it to be perfect. I guess I have to realize that at 11.5 years old, it's like the Millennium Falcon. Always in need of something, but still bad *** in a fight.
Mudding
Joined: Jul 2015
Posts: 151
Likes: 12
From: Los Angeles
Sorry Coil-over believers...I still love the EAS.
Winching
Joined: Jul 2012
Posts: 547
Likes: 4
From: Jackson NJ
Pics or it didn't happen
